神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-002[00]) - VALVE MECHANISM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
429 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3420400200 | [4] | OVERSIZE INLET VALVE | KOB |
| 2. | VA3670401601 | [4] | STD EXHAUST VALVE | KOBSTD ENGINE EXHAUST VALVE |
| 3. | VA3670402100 | [8] | SPRING | KOBValve Outer |
| 4. | VA3060431601 | [8] | RETAINER | KOBUpper |
| 5. | VA3440402901 | [16] | COTTER PIN | KOBValve |
| 6. | VA3060422801 | [8] | SEAL | KOBValve Stem |
| 7. | VA3130411700 | [8] | CAP | KOB |
| 8. | VA3440402013 | [4] | ROCKER | KOBAssy. |
| 9. | VAF232508000 | [4] | JAM NUT | KOB |
| 10. | VAMH001002 | [4] | SCREW | KOBAdjusting Superseded by part number: VAME220221 |
| 11. | VA3160413100 | [4] | BUSHING | KOB |
| 12. | NSS | [4] | NOT SOLD SEPARAT | CONRocker Arm |
| 13. | VA3430400020 | [4] | ROCKER | KOBAssy. Superseded by part number: VA3440402013 |
| 14. | VAF232508000 | [4] | JAM NUT | KOB |
| 15. | VAMH001002 | [4] | SCREW | KOBAdjusting Superseded by part number: VAME220221 |
| 16. | VA3160413100 | [4] | BUSHING | KOB |
| 17. | NSS | [4] | NOT SOLD SEPARAT | CONRocker Arm |
| 18. | VA3440404015 | [1] | SHAFT | KOBAssy., Rocker |
| 19. | VAF501012000 | [1] | EXPANSION PLUG | KOB |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONShaft, Rocker |
| 21. | VA3440414700 | [4] | BRACKET | KOBRocker Shaft |
| 22. | VA3440404600 | [3] | SPRING | KOBRocker Shaft |
| 23. | VA3410474400 | [2] | WASHER | KOB |
| 24. | VA3040404300 | [2] | SNAP RING | KOB |
| 25. | VA3440403500 | [1] | PIPE | KOBOil |
| 26. | VAMF241253 | [4] | SCREW | KOBW/ Washer |
| 27. | VAMF241266 | [4] | BOLT | KOBW/ Washer |
| 28. | VAMF650113 | [1] | EYEBOLT | KOB |
