神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-001[00]) - CYLINDER HEAD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
596 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G0111011 | [1] | Head Assy., Cylinder | |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONHead, Sub Assy., Cyl. |
| 3. | VA0482622500 | [4] | PLUG | KOBCap, Sealing Superseded by part number: VAMF665538 |
| 4. | VA0482623000 | [11] | PLUG | KOBCap, Sealing |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONHead, Cylinder |
| 6. | VA3430101600 | [4] | STD EXHAUST VALVE | KOBSTD ENGINE EXHAUST VALVE Seat, Exhaust Valve |
| 7. | VA32G0102101 | [4] | VALVE SEAT | KOBInlet Valve |
| 8. | VA3430101200 | [4] | Inlet Valve | |
| 9. | VA3430101300 | [4] | Exhaust Valve | |
| 10. | VA0594600801 | [1] | WASHER, SEALING | KOBSEAL WASHER |
| 11. | VAF500008000 | [1] | DRAIN PLUG | KOB |
| 12. | VA32E0102100 | [1] | CYLINDER HEAD GASKET | KOB |
| 13. | VA32F0100500 | [17] | BOLT | KOBCylinder Head |
