纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (03-040-02[01]) - FUEL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
206 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 16. | 87385635 | [1] | INJECTION PIPE | ISUInj. N°1 |
| 17. | 87385639 | [1] | INJECTION PIPE | ISUInj. N°2 |
| 18. | 87385640 | [1] | INJECTION PIPE | ISUInj. N°3 |
| 19. | 87385647 | [1] | INJECTION PIPE | ISUInj. N°4 |
| 20. | 87385649 | [1] | INJECTION PIPE | ISUInj. N°5 |
| 21. | 87385650 | [1] | INJECTION PIPE | ISUInj. N°6 |
| 31. | 87385689 | [6] | FUEL SYSTEM INJECTOR | ISU |
| 58. | 87385692 | [6] | CLAMP | ISU |
| 61. | 426409A1 | [6] | BOLT | ISU |
| 66. | 87385693 | [6] | GASKET | ISU |
| 69B. | 87385696 | [1] | BRACKET | ISU |
| 71B. | 288982A1 | [1] | BOLT | ISUM6 x 12 Superseded by part number: 87595952 |
| 113A. | 87379780 | [11] | CLIP | ISU |
| 113B. | 87379781 | [11] | CLIP | ISU |
| 113C. | 87385698 | [2] | CLIP | ISU |
| 113D. | 87385699 | [2] | CLIP | ISU |
| 119. | 426438A1 | [13] | BOLT | ISUM6 x 30 |
| 124A. | 426418A1 | [6] | BOLT | ISUM8 x 18 |
| 124C. | 426642A1 | [1] | BOLT | ISUM12 x 27 Superseded by part number: 84164363 |
| 126A. | 76600584 | [6] | SEALING RING | ISUSEALRING Superseded by part number: 438172A1 |
| 126B. | 87385745 | [1] | GASKET | ISU |
| 126C. | 426423A1 | [1] | GASKET | ISU Superseded by part number: 289094A1 |
| 137. | 87385788 | [1] | RETURN PIPE | ISU |
| 154. | 87379795 | [1] | GASKET | ISU |
| 210A. | 87385791 | [1] | INJECTION PIPE | ISU |
| 210B. | 87385793 | [1] | INJECTION PIPE | ISU |
| 211. | 87385794 | [1] | MANIFOLD | ISU |
| 284. | 87385800 | [1] | ADAPTER | ISU |
