神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-012[00]) - CONNECTING-ROD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
569 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32F1900012 | [4] | Connecting | |
| 2. | VAME012232 | [8] | SPECIAL BOLT | KOBConnecting-Rod |
| 3. | VAME023570 | [8] | NUT | KOBConnecting-Rod |
| 4. | NSS | [4] | NOT SOLD SEPARAT | CONCap, Connecting-Rod |
| 5. | NSS | [4] | NOT SOLD SEPARAT | CONConnecting-Rod |
| 6. | VA32F1901500 | [4] | BUSHING | KOBCon-Rod |
| 7. | VA32F1902100 | [8] | BEARING LINER | KOBCon-Rod |
| 8. | VA32F1902200 | [8] | BEARING | KOBCon-Rod |
| 9. | VA32F1902300 | [8] | BEARING | KOBCon-Rod |
| 10. | VA32F1902400 | [8] | BEARING | KOBCon-Rod |
