纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (03-041-01[01]) - FUEL FILTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
240 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87385856 | [1] | FUEL FILTER | ISU Superseded by part number: 84147144, 84147141, 289093A1 |
| 2. | 87365565 | [3] | FUEL FILTER | ISU Superseded by part number: 84273157 |
| 11. | 87379063 | [1] | GASKET | ISU |
| 17. | 87379072 | [2] | FLOAT | ISU |
| 38. | 87386020 | [2] | PLUG | ISU |
| 41. | 87386021 | [1] | BRACKET | ISU |
| 42A. | 288701A1 | [2] | BOLT | ISUM10 x 80 |
| 42B. | 355651A1 | [4] | BOLT | ISUM10 x 40 |
| 43A. | 288993A1 | [4] | FLANGE BOLT | ISUM10 x 20 |
| 43B. | 443708A1 | [2] | BOLT | ISUM10 x 120 |
| 57. | 87379078 | [2] | PLUG | ISU |
