纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (03-042-01[01]) - FUEL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
390 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 46. | 355640A1 | [1] | BOLT | ISU |
| 107. | 87386022 | [1] | PIPE | ISU |
| 108. | 87386023 | [1] | BOLT | ISUM14 x 42 |
| 110A. | 288565A1 | [7] | GASKET | ISU Superseded by part number: 72110175 |
| 110B. | 87384800 | [4] | GASKET | ISU |
| 112A. | 87386024 | [2] | BOLT | ISU |
| 112B. | 87386025 | [1] | BOLT | ISU |
| 119. | 87386027 | [1] | RETURN PIPE | ISU |
| 123A. | 87538326 | [1] | PIPE | ISU |
| 123B. | 87386029 | [1] | RETURN PIPE | ISU |
| 125A. | 426437A1 | [3] | MOUNTING CLIP | ISUID=10 & 10 L=25 Superseded by part number: 87384507 |
| 125B. | 426431A1 | [3] | MOUNTING CLIP | ISU Superseded by part number: 72110435 |
| 125C. | 87379780 | [1] | CLIP | ISU |
| 125D. | 87379781 | [1] | CLIP | ISU |
| 126. | 87531032 | [4] | BOLT | ISU |
| 131A. | 87386031 | [1] | BRACKET | ISU |
| 131B. | 87386032 | [1] | BRACKET | ISU |
| 148. | 288993A1 | [2] | FLANGE BOLT | ISUM10 x 20 |
| 150. | 289091A1 | [2] | PACKING | ISU |
| 191A. | 426418A1 | [1] | BOLT | ISUM8 x 18 |
| 191B. | 87379797 | [2] | BOLT | ISUM16 x 30 |
| 212. | 87386033 | [2] | VALVE | ISU Superseded by part number: 47706995 |
| 329A. | 87386034 | [1] | PIPE | ISU |
| 329B. | 87386035 | [2] | PIPE | ISU |
