纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (04-001-00[01]) - CHASSIS ELECTRICAL CIRCUIT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
929 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUR10070 | [1] | HARNESS | SUM |
| 2. | 150860A1 | [1] | COLLAR | SUM |
| 3. | 840-168 | [1] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
| 4. | 150496A1 | [1] | MOUNTING CLIP | SUM250 mm |
| 5. | KHR2581 | [3] | CLAMP | SUM |
| 6. | KHJ1215 | [3] | BOLT,Spcl | SUMM8 x 25 |
| 7. | KHR2787 | [2] | CLAMP | SUM |
| 11. | KHR2713 | [1] | ELECTRIC CABLE | SUM |
| 12. | 156559A1 | [1] | BOLT,High Strength, Hex, M6 x 12mm, W/ LW | SUMM6 x 12 |
| 13. | 159602A1 | [1] | BOLT,Sems, Hex, M6 x 16mm | SUMM6 x 16 |
| 14. | 893-11006 | [2] | LOCK WASHER,Ext Tooth, M6 | CAS Superseded by part number: 86625265 |
| 16. | 150520A1 | [1] | GROMMET | SUM |
| 26. | 167518A1 | [1] | BOLT | SUMM8 x 16 |
| 27. | 893-11008 | [1] | LOCK WASHER,Ext Tooth, M8 | CAS Superseded by part number: 86632601 |
| 43. | KUR0067 | [2] | GROMMET | SUM360 mm |
| 45. | KHR4332 | [1] | GROMMET | SUM315 mm |
| 84. | KHR4313 | [1] | BRACKET | SUM Superseded by part number: KTR11880 |
| 85. | 166352A1 | [4] | BOLT | SUMM12 x 30 |
| 86. | KTR0521 | [1] | PAD, RUBBER | SUM Superseded by part number: KHR17390 |
| 87. | KMR0766 | [1] | PLATE | SUM |
| 89. | KHR4314 | [1] | COVER | SUM Superseded by part number: KTR11880 |
| 91. | KHR12950 | [1] | FUSE | SUM |
| 92. | 159902A1 | [1] | FUSE | SUM |
| 93. | KHR2584 | [2] | CLAMP | SUM |
| 94. | KHR2309 | [2] | BOLT,Spcl | SUMM8 x 30 |
| 95. | 159897A1 | [1] | RELAY | SUM |
| 100. | 145N005S016N | [2] | SCREW,Pan Hd, M5 x 16mm | SUMM5 x 16 |
| 101. | KHR12370 | [1] | POS BATTERY CABLE | SUM |
| 102. | KHR12100 | [1] | POS BATTERY CABLE | SUM |
| 103. | KHR12190 | [1] | POS BATTERY CABLE | SUM |
| 104. | KHR10170 | [1] | POS BATTERY CABLE | SUM |
| 105. | 162212A1 | [2] | TERMINAL CONNECTOR | SUM |
| 106. | 159171A1 | [2] | CAP | SUM |
| 107. | 162150A1 | [2] | CLAMP | SUM |
| 114. | KNR0617 | [1] | GROMMET | SUM |
| 115. | 159656A1 | [1] | GROMMET | SUM |
