神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-018[00]) - EXHAUST SYSTEM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
390 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3423221600 | [1] | EXHAUST MANIFOLD | KOB |
| 2. | VA3423201700 | [1] | GASKET | KOBExhaust |
| 3. | VA3433200301 | [4] | STUD | KOB |
| 4. | VA3423200300 | [1] | GASKET | KOBExhaust |
| 5. | VA3233200801 | [8] | NUT | KOBLock |
| 6. | VA3433200700 | [8] | STUD | KOB |
| 7. | VA3433201202 | [6] | SPACER | KOB |
| 8. | VA3433231301 | [8] | WASHER | KOB |
| 9. | VA32A3202300 | [8] | FLANGE NUT | KOB |
| 10. | VAF500510001 | [1] | PLUG | KOBTapered |
| 11. | VA3433221401 | [2] | SPACER | KOB |
| 12. | VAF232008000 | [2] | NUT | KOB |
