神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-017[00]) - INLET SYSTEM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
661 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G3010100 | [1] | INLET MANIFOLD | KOB |
| 2. | VA32G3000200 | [1] | GASKET | KOBInlet |
| 3. | VA3673001053 | [1] | ELBOW | KOBAssy. Superseded by part number: VA3673001051 |
| 4. | VA3433004300 | [1] | GASKET | KOBAir Heater |
| 5. | VAMF241266 | [4] | BOLT | KOBW/Washer |
| 6. | VAF103508090 | [9] | BOLT | KOB |
| 7. | VAF103508035 | [9] | BOLT | KOB |
| 8. | VAF251508000 | [18] | SPRING WASHER | KOB |
| 9. | VAF250008000 | [18] | WASHER | KOBPlain |
| 10. | VA32G8708101 | [5] | BRACKET | KOBHarness |
| 11. | VAMF241252 | [6] | BOLT | KOBW/Washer |
| 12. | VA32G9001101 | [1] | Harness | |
| 13. | VA32G6103800 | [1] | BRACKET | KOBInj.pipe |
