神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-021[00]) - OIL STRAINER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
357 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32A3610010 | [1] | SAFETY VALVE | KOBAssy. |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONCase, Valve |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONSeat, Spring |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPin, Spring |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONSpring |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONBall, Steel |
| 7. | VAF420218000 | [1] | SEAL | KOB |
| 8. | VA32G3500200 | [1] | FILTER STRAINER | KOBOil |
| 9. | VA3423501201 | [1] | STAY | KOB Superseded by part number: VA3423501200 |
| 10. | VAF182508016 | [2] | BOLT | KOBW/Washer |
| 11. | VAF315602500 | [1] | O-RING | KOB |
| 12. | VA180508016 | [1] | W/Washer | |
