神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-023[00]) - OIL FILTER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
383 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G4001100 | [1] | ENGINE OIL FILTER | KOBOil Filter |
| 2. | VA3424010200 | [1] | COVER | KOBOil |
| 3. | VA3424004200 | [1] | GASKET | KOBOil Filter |
| 4. | VA3434003021 | [1] | VALVE PRESSURE RELIE | KOBAssy. |
| 5. | VA0531750221 | [1] | CLAMP | KOB |
| 6. | VAMF244853 | [2] | BOLT | KOBW/Washer |
| 7. | VAMF241268 | [1] | BOLT | KOBW/Washer |
| 8. | VA3434000700 | [1] | SEAL | KOB |
| 9. | VAF200510025 | [4] | BOLT | KOBW/Washer |
| 10. | VAF201510030 | [4] | BOLT | KOBW/Washer |
| 11. | VAF115510020 | [1] | BOLT | KOB |
| 12. | VAF200510040 | [2] | BOLT | KOBW/Washer |
| 13. | VA3434011084 | [1] | BASE | KOBAssy., Filter |
| 14. | VA0482772100 | [2] | PLUG | KOBTapered |
| 15. | VA3434004800 | [1] | DRAIN PLUG | KOB |
| 16. | VA3434014502 | [1] | BASE | KOBFilter |
| 17. | VAF420230000 | [1] | GASKET | KOB |
| 18. | VA3434021071 | [1] | BRACKET | KOBAssy., Filter |
| 19. | VA0556375904 | [1] | O-RING | KOB |
| 20. | VA3434000061 | [1] | VALVE PRESSURE RELIE | KOBAssy. |
| 21. | VA3434000700 | [1] | SEAL | KOB |
| 22. | VA3434002600 | [1] | HYD CONNECTOR | KOB |
| 23. | VA3434003601 | [1] | VALVE | KOB |
| 24. | VA3434005100 | [1] | PIPE | KOBDrain |
| 25. | VA3434014700 | [1] | BOLT | KOBValve |
| 26. | VA3434024601 | [1] | Oil Filter | |
| 27. | VAF232016000 | [1] | JAM NUT | KOB Superseded by part number: VAF232516000 |
| 28. | VA0550700280 | [2] | O-RING | KOB |
| 29. | VA3434001900 | [1] | GASKET | KOBFilter Bracket |
| 30. | VAMF241264 | [1] | BOLT | KOBW/Washer |
| 31. | VA3434003701 | [1] | CAP | KOB |
| 32. | VAF250010000 | [4] | SPRING WASHER | KOBPlain |
| 33. | VAF250008000 | [1] | WASHER | KOBPlain |
| 34. | VA32G4000100 | [1] | HOSE | KOBDrain |
| 35. | VA32G8708301 | [1] | Harness | |
| 36. | VA32A1302300 | [2] | FLANGE BOLT | KOB |
