纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (04-810-01[01]) - ELECTRICAL ACCESSORIES - ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
297 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 13. | 87386269 | [1] | HARNESS | ISU |
| 16A. | 76591845 | [1] | CLIP | ISUID=19 L=25 |
| 16B. | 87386272 | [1] | CLIP | ISUID=14.5 L=30 |
| 16C. | 87386274 | [2] | CLIP | ISUID=18 L=28 |
| 16D. | 87386276 | [1] | CLIP | ISUID=20 L=27 |
| 16E. | 87386277 | [1] | CLIP,31mm ID, P Type | ISUID=31 L=35 |
| 16F. | 87386278 | [1] | CLIP | ISUID=28 L=40 |
| 16G. | 87386279 | [2] | CLIP | ISUID=14.5 L=20 |
| 16H. | 87386280 | [1] | CLIP | ISUID=6.5 Superseded by part number: 87597784 |
| 16I. | 87386283 | [1] | CLIP | ISUID=16 L=22 |
| 16J. | 87384811 | [3] | CLIP | ISUID=19 L=20 |
| 53A. | 87386291 | [1] | BRACKET | ISU |
| 53B. | 87380142 | [1] | BRACKET | ISU |
| 53C. | 87377931 | [1] | BRACKET | ISU |
| 139A. | 355226A1 | [1] | BOLT | ISUM8 x 20 |
| 139B. | 426275A1 | [1] | BOLT | ISUM10 x 16 Superseded by part number: 87597950 |
| 150A. | 419935A1 | [7] | BOLT | ISUM8 x 16 Superseded by part number: 76599954 |
