纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (05-002-00[01]) - ROLLER UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
534 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUA10150 | [6] | TRACK ROLLER | SUM |
| 2. | KUA0307 | [1] | TRACK ROLLER | SUM |
| 3. | KUA10350 | [1] | SHAFT | SUM |
| 4. | KUA10160 | [1] | SHAFT | SUM |
| 5. | KUA10360 | [1] | COLLAR | SUM |
| 6. | KUA0312 | [1] | COVER | SUM |
| 7. | KUA0313 | [1] | PLATE | SUM |
| 8. | KUA0314 | [1] | ROLLER BEARING | SUM |
| 9. | KUA0315 | [1] | ROLLER BEARING | SUM Superseded by part number: 00146640 |
| 10. | 165829A1 | [1] | SEAL | SUM |
| 11. | KAJ1264 | [1] | O-RING | SUM Superseded by part number: 154766A1 |
| 12. | 863-16040 | [3] | HEX SOC SCREW,M16 x 40mm, Cl 12.9 | CASM16 x 40 |
| 13. | KUA0320 | [4] | SCREW | SUMM14 x 40 |
| 14. | 892-16014 | [4] | LOCK WASHER,M14, Hvy | SUMSW 14 |
| 15. | KUA0322 | [1] | PLUG | SUM |
| 16. | KUA0377 | [1] | SHIM | SUM |
| 17. | 827-20100 | [12] | BOLT,Hex, M20 x 2.5 x 100mm, Cl 10.9 | CAS Superseded by part number: 9843612 |
| 18. | 150817A1 | [12] | WASHER,21mm ID x 40mm OD x 4.5mm Thk | SUMW 20 |
