神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-032[00]) - STARTER (24V-5KW) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
627 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G6610100 | [1] | STARTER MOTOR,24V, 5kW | KOBAssy. |
| 2. | VA32G6607100 | [1] | | |
| 3. | VA32G6607110 | [1] | | |
| 4. | VA32G6617120 | [1] | | |
| 5. | VA32G6607130 | [2] | | |
| 6. | VA32G6607140 | [2] | | |
| 7. | VA32G6607150 | [1] | Magnet | |
| 8. | VA32G6607160 | [2] | | |
| 9. | VA32G6607170 | [2] | | |
| 10. | VA32G6607180 | [1] | Rear | |
| 11. | VA32G6607190 | [1] | Holder | |
| 12. | VA32G6607200 | [1] | | |
| 13. | VA32G6607210 | [1] | | |
| 14. | VA32G6607220 | [1] | | |
| 15. | VA32G6607230 | [1] | | |
| 16. | VA32G6607240 | [4] | Plant | |
| 17. | VA32G6607250 | [1] | | |
| 18. | VA32G6607260 | [1] | | |
| 19. | VA32G6607270 | [1] | | |
| 20. | VA32G6607280 | [1] | | |
| 21. | VA32G6607290 | [1] | | |
| 22. | VA32G6607300 | [1] | | |
| 23. | VA32G6607310 | [2] | | |
| 24. | VA32G6607320 | [1] | | |
| 25. | VA32G6607330 | [1] | Gear | |
| 26. | VA32G6607340 | [1] | | |
| 27. | VA32G6607350 | [1] | Gear | |
| 28. | VA32G6607360 | [1] | Front | |
| 29. | VA32G6607370 | [1] | Safety | |
| 30. | VA32G6607380 | [2] | | |
| 31. | VA32G6607390 | [2] | | |
