神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-031[02]) - INJECTION PUMP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
788 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G6100300 | [1] | FUEL INJECTION PUMP | KOBHigh Pressure Superseded by part number: VA32G6100301 |
| 2. | VA32G6107100 | [1] | O-RING | KOB |
| 3. | VA32G6107010 | [1] | | |
| 4. | VA32G6107200 | [1] | FUEL PUMP | KOBFeed Superseded by part number: VA32G6107070 |
| 5. | VA32G6107300 | [1] | SEAL | KOBFeed Pump |
| 6. | VA32G6107400 | [1] | SCREW | KOBFeed Pump |
| 7. | VA32G6107020 | [1] | MOTOR | KOBAssembly, Mprop=SCV (Suction Control Valve) Superseded by part number: VA32G6107700, VA32G6107080, VA32G6107800 |
| 8. | VA32G6107500 | [1] | VALVE | KOB Superseded by part number: VA32G6107080 |
| 9. | VA32G6107600 | [1] | O-RING | KOBMprop |
| 10. | VA32G6107700 | [1] | GASKET | KOBMprop |
| 11. | VA32G6107800 | [3] | SCREW | KOBMprop |
| 12. | VA32G6107030 | [1] | FLOW CONTROL VALVE | KOB |
| 13. | VA32G6107900 | [1] | VALVE | KOBOverflow Superseded by part number: VA32G6107030 |
| 14. | VA32G6108100 | [1] | O-RING | KOBOverflow |
| 15. | VA32G6107040 | [1] | | |
| 16. | VA32G6108200 | [1] | HYD CONNECTOR | KOBInlet |
| 17. | VA32G6108300 | [1] | GASKET | KOBInlet |
| 18. | VA32G6107050 | [1] | | |
| 19. | VA32G6108400 | [1] | HYD CONNECTOR | KOBOutlet |
| 20. | VA32G6108500 | [1] | GASKET | KOBOutlet |
