神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-034[01]) - ALTERNATOR (GENERAL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
127 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G6800100 | [1] | ALTERNATOR | KOB |
| 2. | VA32G6801101 | [1] | Adjusting | |
| 3. | VAF200510025 | [2] | BOLT | KOBW/Washer |
| 4. | VA32G6802500 | [1] | BOLT | KOBSet |
| 5. | VA32G6802400 | [1] | PULLER | KOB |
| 6. | VA32G6802100 | [1] | SPACER | KOB |
| 7. | VA32G6802200 | [1] | SPACER | KOB |
| 8. | VA32G6802301 | [1] | NUT | KOBStopper |
| 9. | VA0597814150 | [1] | BOLT | KOB |
| 10. | VAF251514000 | [1] | SPRING WASHER | KOB |
| 11. | VAF251512000 | [1] | SPRING WASHER | KOB |
| 12. | VAF230512000 | [2] | NUT | KOB |
