神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-034[02]) - ALTERNATOR (24V-50A) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
465 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA32G6800100 | [1] | ALTERNATOR | KOB |
| 2. | VA32G6807100 | [3] | | |
| 3. | VA32G6807110 | [1] | | |
| 4. | VA32G6807120 | [3] | | |
| 5. | VA32G6807130 | [1] | NUT | KOB |
| 6. | VA32G6807140 | [1] | SPRING WASHER | KOB |
| 7. | VA32G6807150 | [1] | SPRING WASHER | KOBPlain |
| 8. | VA32G6807160 | [1] | PULLEY | KOB |
| 9. | VA32G6807170 | [1] | | |
| 10. | VA32G6807180 | [2] | | |
| 11. | VA32G6807190 | [3] | | |
| 12. | VA32G6807200 | [1] | | |
| 13. | VA32G6807210 | [1] | BEARING ASSY | KOBFront Superseded by part number: VA32G6807361 |
| 14. | VA32G6807220 | [1] | Front | |
| 15. | VA32G6807230 | [1] | BEARING ASSY | KOBRear |
| 16. | VA32G6807240 | [1] | | |
| 17. | VA32G6807250 | [3] | | |
| 18. | VA32G6807260 | [1] | COIL | KOBField |
| 19. | VA32G6807270 | [1] | Coil | |
| 20. | VA32G6807280 | [1] | | |
| 21. | VA32G6807290 | [1] | VOLTAGE REGULATOR | KOB |
| 22. | VA32G6807300 | [1] | | |
| 23. | VA32G6807310 | [1] | COMMUTATOR BRUSH | KOBInsulite |
| 24. | VA32G6807320 | [1] | COMMUTATOR BRUSH | KOBInsulite |
| 25. | VA32G6807330 | [1] | CONDENSER | KOB |
| 26. | VA32G6807340 | [1] | RECTIFIER | KOB |
| 27. | VA32G6807350 | [1] | Rear | |
