纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (06-001-00[01]) - TRAVEL MOTOR AND REDUCTION GEAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1006 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUA10170 | [2] | SPROCKET | SUM |
| 2. | 102R027Y090N | [48] | BOLT | SUMM27 x 90 |
| 3. | 102R027Y100N | [52] | BOLT | SUMM27 x 100 |
| 4. | 157544A1 | [100] | WASHER | SUMW27 |
| 5. | KUA10590 | [2] | MOTO-REDUCTION GEAR | SUM |
| 6. | KUA10580 | [1] | REDUCER | SUM |
| 54. | 151524A1 | [1] | O-RING | SUM |
| 55. | KUA0282 | [1] | MOTOR, HYDRAULIC | SUM |
| 56. | 150807A1 | [8] | BOLT,Hex Skt, M18 x 2.5 x 50mm | SUMM18 x 50 |
