纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (06-002-00[01]) - SWING MOTOR-DRIVE REDUCTION GEAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
998 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUC10010 | [2] | HYDRAULIC MOTOR | SUM |
| . . | KUC10010R | [2] | REMAN-HYD MOTOR | SUME805 TIER 3 (7/06-) |
| . . | KUC10010C | [1] | CORE-MOTOR HYDRAULIC | SUMReturn Number |
| 2. | KUC10020 | [2] | REDUCER | SUM |
| 38. | 800-1145 | [2] | SNAP RING,M45, Ext | CAS Superseded by part number: 370007 |
| 39. | KUC0013 | [2] | PINION | SUM |
| 40. | 150285A1 | [2] | PLATE, LOCKING | SUM |
| 41. | 167069A1 | [2] | WASHER | SUMW125 |
| 42. | 627-16040 | [4] | BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 374835 |
| 43. | 150317A1 | [2] | HEADED PIN,24mm OD x 90mm L | SUM |
| 44. | 166477A1 | [24] | BOLT,Sems, M24 x 90mm | SUMM24 x 90 |
| 45. | KHJ1255 | [1] | HYDRAULIC HOSE,12.70 mm ID x 500.00 mm | SUM |
| 46. | KWJ10020 | [1] | HOSE ASSY.,12.70 mm ID x 700.00 mm | SUM |
| 47. | KHR4065 | [1] | PLASTIC-RUBBER TUBE | SUM350 mm Superseded by part number: KHR21050 |
| 48. | 158060A1 | [1] | PLASTIC-RUBBER TUBE | SUM700 mm Superseded by part number: KHR21050 |
| 49. | KHP0578 | [2] | PLUG | SUM |
| 50. | KRJ4050 | [6] | ADAPTER | SUM |
| 51. | 167867A1 | [1] | HYDRAULIC HOSE,6.30 mm ID x 800.00 mm | SUM300 mm |
| 52. | 167862A1 | [1] | HYDRAULIC HOSE,6.30 mm ID x 750.00 mm | SUM |
| 53. | 167317A1 | [1] | HYDRAULIC HOSE,6.30 mm ID x 900.00 mm | SUM |
| 54. | KHJ1114 | [1] | HYDRAULIC HOSE,6.35 mm ID x 850.00 mm | SUM |
| 55. | 157692A1 | [1] | PLASTIC-RUBBER TUBE | SUM800 mm Superseded by part number: |
| 56. | KBR0621 | [1] | LOOM | SUM650 mm |
| 57. | 153912A1 | [2] | LUBE NIPPLE,90º, 1/8"-27 NPT x 21.5mm lg | SUM |
| 58. | 169177A1 | [2] | PLUG | SUM |
| 59. | KHR2584 | [4] | CLAMP | SUM |
| 60. | KHJ1215 | [4] | BOLT,Spcl | SUMM8 x 25 |
| 61. | 150071A1 | [1] | MOUNTING CLIP | SUM380 mm |
| 62. | 150860A1 | [1] | COLLAR | SUM |
| 63. | 840-168 | [1] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
| 64. | 150496A1 | [1] | MOUNTING CLIP | SUM250 mm |
