纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (06-011-00[01]) - SWING REDUCTION GEAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
223 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | KUC10020 | [1] | REDUCER | SUM |
| 4. | KUC10050 | [1] | SUN GEAR | SUM |
| 5. | KSC0212 | [1] | PLATE, THRUST | SUM |
| 6. | KSC0245 | [1] | CARRIER | SUM |
| 7. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 11. | KSC0246 | [1] | CARRIER | SUM |
| 17. | KSC0219 | [1] | SUN GEAR | SUM |
| 18. | KUC10060 | [1] | RING GEAR | SUM |
| 19. | KTC0155 | [4] | PIN | SUM |
| 20. | KUC10070 | [1] | HOUSING | SUM |
| 21. | KSC0207 | [1] | BEARING,120mm ID x 200mm OD x 62mm W | SUM |
| 22. | KSC0210 | [1] | SPACER | SUM |
| 23. | 150824A1 | [1] | PLUG | SUM |
| 24. | KTC0153 | [1] | OIL SEAL | SUM |
| 25. | 158352A1 | [2] | PLUG | SUM |
| 26. | KSC0249 | [1] | SPACER | SUM |
| 27. | 150491A1 | [1] | ROLLER BEARING,130mm ID x 280mm OD x 93mm W | SUM |
| 28. | KSC0250 | [1] | BEARING COVER | SUM |
| 29. | KSC0251 | [1] | RETAINING WIRE | SUM |
| 30. | KSC0214 | [1] | SPACER | SUM |
| 31. | KUC10080 | [1] | GEAR SHAFT | SUM |
| 33. | 150483A1 | [12] | BOLT,Hex Skt, M20 | SUM |
| 34. | 150435A1 | [1] | COLUMN JACKET | SUM |
| 35. | 150438A1 | [1] | GAUGE | SUM |
