纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (07-001-00[01]) - HYDRAULIC CIRCUIT - UNDERCARRIAGE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
691 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 164450A1 | [12] | O-RING | SUM |
| 2. | 150124A1 | [24] | FLANGE | SUM |
| 3. | 108R014Y045R | [48] | BOLT,Hex Skt, M14 x 45mm, Cl 12.9 | SUMM14 x 45 |
| 4. | KUA0142 | [4] | HYDRAULIC HOSE,31.80 mm ID x 1300.00 mm | SUM |
| 5. | KUA0376 | [4] | HYDRAULIC HOSE,31.80 mm ID x 2050.00 mm | SUM |
| 6. | 155211A1 | [4] | O-RING | SUM Superseded by part number: 86529541 |
| 7. | 150561A1 | [8] | FLANGE | SUM |
| 8. | 862-12040 | [16] | HEX SOC SCREW,M12 x 40mm, Cl 12.9 | CAS Superseded by part number: 108R012Y040R |
| 9. | 152127A1 | [2] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 10. | 154467A1 | [2] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 11. | 161482A1 | [2] | HOSE ASSY. | SUM1500 mm |
| 12. | KAJ2840 | [2] | ELBOW | SUM |
| 14. | 167352A1 | [2] | HOSE,2500.00 mm | SUM |
| 15. | 151654A1 | [2] | HYD CONNECTOR,3/4" NPT O-Ring x 3/4" NPT | SUM |
| 16. | 154503A1 | [2] | O-RING | SUM |
| 17. | KUA0144 | [2] | HYDRAULIC HOSE,15.90 mm ID x 1500.00 mm | SUM |
| 18. | KUA0145 | [2] | HYDRAULIC HOSE,15.90 mm ID x 2200.00 mm | SUM |
| 18.01. | 159198A1 | [2] | ADAPTER | SUM |
| 19. | 157580A1 | [2] | ELBOW,90º, 3/4" O-Ring x 3/4" | SUM |
| 21. | KUA0147 | [1] | SUPPORT | SUM |
| 22. | KUA0189 | [1] | SUPPORT | SUM |
| 23. | KUA0146 | [2] | MANIFOLD | SUM |
| 24. | 159481A1 | [2] | ADAPTER | SUM |
| 25. | KHJ0508 | [2] | FITTING | SUM |
| 26. | 827-16110 | [4] | BOLT,Hex, M16 x 2 x 110mm, Cl 10.9 | CAS Superseded by part number: 84036080 |
| 27. | 627-12025 | [4] | BOLT,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | CAS Superseded by part number: 398792 |
| 28. | 150814A1 | [4] | WASHER,17mm ID x 32mm OD x 4.5mm Thk | SUM |
| 29. | 150811A1 | [4] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 30. | 150071A1 | [16] | MOUNTING CLIP | SUM |
