纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (07-012-00[01]) - TRAVEL MOTOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
740 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4. | NSS | [1] | NOT SERVICED SEPARATELY | CONSpool |
| 9. | 154475A1 | [2] | O-RING | SUM |
| 13. | LR012400 | [2] | CAP | SUM |
| 17. | 154455A1 | [1] | O-RING | SUM |
| 18. | 154569A1 | [1] | O-RING | SUM |
| 19. | 863-12050 | [4] | HEX SOC SCREW,M12 x 50mm, Cl 12.9 | SUMM12 x 50 Superseded by part number: 86511099 |
| 20. | LJ013300 | [2] | PRESSURE RELIEF VALVE | SUM |
| 29. | 829-1012 | [1] | NUT,M12, Cl 10 | CAS |
| 31. | 154471A1 | [1] | O-RING | SUM |
| 32. | 154487A1 | [1] | O-RING | SUM |
| 33. | 154495A1 | [1] | O-RING | SUM |
| 34. | 155225A1 | [1] | O-RING | SUM |
| 35. | 153958A1 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 36. | 153970A1 | [2] | BACK-UP RING | SUMRING, BACK-UP |
| 37. | 153977A1 | [2] | BACK-UP RING | SUMRING, BACK-UP |
| 42. | 154447A1 | [1] | O-RING | SUM |
| 43. | 154443A1 | [1] | O-RING | SUM |
| 44. | 153940A1 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 45. | 153937A1 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 46. | 168420A1 | [1] | SNAP RING | SUM |
| 47. | 154451A1 | [2] | O-RING | SUM |
| 48. | 156880A1 | [2] | ORIFICE | SUM |
| 49. | LG00343 | [1] | COMPRESSION SPRING | SUM |
| 50. | LK00329 | [1] | PLUG | SUM |
| 52. | LS00127 | [1] | GUIDE | SUM |
| 53. | LK00306 | [1] | PLUG | SUM |
| 54. | 895-10010 | [1] | WASHER,11mm ID x 20mm OD x 2mm Thk | CAS Superseded by part number: 14496621 |
| 100. | LZ00458 | [1] | SEAL KIT | SUM |
| 101. | LZ00459 | [1] | SEAL KIT | SUM |
