纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-001-00[01]) - HYDRAULIC RESERVOIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
809 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KWJ0064 | [1] | HYDRAULIC OIL RESERVOIR | SUM |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | 153340A1 | [2] | COVER | SUM |
| 4. | KUJ0246 | [1] | COVER | SUM |
| 5. | 154909A1 | [1] | O-RING | SUM |
| 6. | KHJ1252 | [2] | O-RING | SUM |
| 7. | KUJ0011 | [1] | HYDRAULIC OIL FILTER | SUM |
| 8. | 166052A1 | [6] | BOLT | SUMM10 x 25 Superseded by part number: 11106231 |
| 9. | 161066A1 | [1] | BREATHER ASSY. | SUM |
| 10. | 159702A1 | [1] | HYDRAULIC OIL FILTER | SUM Superseded by part number: 47587350 |
| 12. | 862-6016 | [4] | HEX SOC SCREW,M6 x 16mm, Cl 12.9 | CASM6 x 16 |
| 13. | 892-11006 | [4] | LOCK WASHER,M6 | CAS Superseded by part number: 86517328 |
| 14. | 153030A1 | [2] | HYDRAULIC OIL FILTER | SUM |
| 15. | 153037A1 | [2] | VALVE | SUM |
| 16. | 153343A1 | [2] | SPRING | SUM |
| 18. | 163560A1 | [1] | SIGHTGLASS | SUM |
| 19. | 163561A1 | [1] | GAUGE | SUM |
| 20. | 159492A1 | [2] | BOLT | SUM |
| 21. | 159493A1 | [4] | SEALING WASHER | SUMSEAL WASHER M10 |
| 25. | 153208A1 | [1] | SHIM | SUM |
| 26. | 153209A1 | [1] | SHIM | SUM |
| 27. | 102R020Y090R | [6] | BOLT | SUMM20 x 90 |
| 28. | KUJ0017 | [6] | SPACER | SUM |
| 30. | KHJ13240 | [1] | BOLT | SUMM24 x 2 x 240 |
| 31. | KHJ13230 | [1] | SEALING WASHER | SUMM24 |
