神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (05-001[00]) - STEP INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
904 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN41C00006F1 | [1] | STEP | KOBInstal |
| 1. | YN41C00007P1 | [4] | STEP,366mm wide | KOB |
| 2. | ZS18C12045 | [8] | SCREW,Hex, M12 x 45mm | KOBCap |
| 3. | ZW26X12000 | [8] | LOCK WASHER | KOB |
| 4. | ZN18C12010 | [8] | NUT | KOB |
| . . | YN41C00006F2 | [1] | STEP | KOBInstal |
| 5. | YN41C00008P1 | [4] | STEP,366mm wide | KOB |
| . . | YN41C00006F3 | [1] | STEP | KOBInstal |
| 6. | YN41C00009P1 | [4] | STEP,366mm wide | KOB |
