神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-001[00]) - FRAME ASSEMBLY, LOW Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
687 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY02F00129F1 | [1] | Low | |
| 1. | YY02F00130P1 | [1] | Low | |
| 2. | YY07F00095P1 | [1] | Crawler | |
| 3. | YY07F01145P1 | [2] | SUPPORT | KOB |
| 4. | YN07F01075P1 | [1] | GUIDE | KOB |
| 5. | YN07F01076P1 | [1] | GUIDE | KOB |
| 6. | YY07F00096P1 | [1] | Crawler | |
| 7. | YY07F01145P1 | [2] | SUPPORT | KOB |
| 8. | YN07F01075P1 | [1] | GUIDE | KOB |
| 9. | YN07F01076P1 | [1] | GUIDE | KOB |
| 10. | YN41C00080P1 | [4] | STEP | KOB |
