神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-007[00]) - TRACK ROLLER ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
161 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN64D00019F1 | [12] | ROLLER | KOBAssembly, Incl 2 - 11, Serial Range: LH02-01501-LH02-01527 Superseded by part number: LQ64D00054F1 |
| 2. | YN64D01021P1 | [1] | ROLLER | KOB |
| 3. | YN64D01041P1 | [2] | COLLAR | KOB |
| 4. | YN64D01042P1 | [1] | SHAFT | KOB Superseded by part number: LQ64D01028P1 |
| 5. | 2405P489 | [2] | BUSHING,66mm ID x 87mm OD x 64.5mm L | KOB |
| 6. | YN64D01043P1 | [2] | PIN | KOB |
| 7. | 2445R441F1 | [2] | SEAL,90mm ID x 114.45mm OD x 33mm Thk | KOBFloating |
| 8. | 2445R441S1 | [2] | SEAL | KOB |
| 9. | 2445R441S2 | [2] | O-RING | KOB |
| 10. | ZD11G06000 | [2] | O-RING,59.40mm ID x 65.60mm OD x 3.10mm | KOB |
| 11. | ZE82T04000 | [2] | PLUG | KOB |
| 12. | 2420P1580D4 | [48] | BOLT,Hex, M18 x 1.5 x 80mm | KOBCap |
