神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-016[00]) - SHOE ASSEMBLY 600MM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
376 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY60D00019F2 | [2] | SHOE (ASSY) | KOBAssembly, Incl 2 - 13 |
| 2. | YY62D00010F2 | [1] | TRACK LINK | SMAssembly, Incl 3 - 10 |
| 3. | 2424J376 | [40] | TRACK LINK | KOB Superseded by part number: 2424J171D1 |
| 4. | 2424J377 | [40] | TRACK LINK | KOB |
| 5. | 2419P4210 | [39] | PIN,36.66mm OD x 206.40mm L | KOB Superseded by part number: 2419T6091 |
| 6. | 2405P415 | [1] | BUSHING | KOBMaster Superseded by part number: 2405P392 |
| 7. | 2419P4211 | [1] | PIN,36.5mm OD x 206.4mm L | KOB |
| 8. | 2418T21131 | [2] | COLLAR | KOB |
| 9. | YN62D01028P1 | [78] | SEAL,37.25mm ID x 60.5mm OD x 14.2mm Thk | KOB |
| 10. | YY62D01018P1 | [39] | BUSHING | SM |
| 11. | YY60D00017P1 | [40] | SHOE | KOB600mm, Curved, Serial Range: LH02-01501-LH02-01527 Superseded by part number: YY60D00057P1 |
| 11. | YY60D00057P1 | [40] | SHOE | KOB600mm, Curved, Start Serial: LH02-01528 |
| 12. | 2420T6976 | [160] | BOLT,Spher Hex, M20 x 1.5 x 56.50mm, Cl 2 | KOB Superseded by part number: 47796204 |
| 13. | 2420P1552 | [160] | NUT,M20, 1.5mm Pitch, HT | KOB Superseded by part number: 2420P1584 |
