神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-017[00]) - DOZER GROUP (PTPA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
568 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY51BU1018P1 | [2] | COVER | KOB |
| 2. | YY51BU1017P1 | [1] | COVER | KOB |
| 3. | YY51BU1016P1 | [1] | COVER | KOB |
| 4. | YY51BU1020P1 | [1] | COVER | KOB |
| 5. | YY51BU1019P1 | [1] | COVER | KOB |
| 6. | YY51BU1077P1 | [8] | RUBBER | KOB |
| 7. | ZW16X08000 | [20] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOB |
| 8. | ZS18C08016 | [4] | SCREW,Hex, M8 x 16mm | KOBCap |
| 9. | ZS18C08060 | [16] | SCREW,Hex, M8 x 60mm | KOBCap |
| 10. | ZS18C10016 | [3] | SCREW,Hex, M10 x 16mm | KOBCap |
| 11. | ZW16H10000 | [5] | WASHER | KOB |
| 12. | ZS18C10090 | [1] | SCREW,Hex, M10 x 90mm | KOBCap |
| 13. | ZN18C10008 | [1] | NUT | KOB |
| 14. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 15. | ZG91U02000 | [3] | LUBE NIPPLE | KOB90° x 1/8" PT |
