纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-029-00[01]) - HYDRAULIC CIRCUIT - ATTACHMENT CONTROL VALVE PILOT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
329 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KHJ1402 | [2] | ADAPTER | SUM |
| 2. | 154475A1 | [1] | O-RING | SUM |
| 3. | 152128A1 | [3] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 5. | 161842A1 | [1] | ADAPTER,3/8" - 19 NPT x 1/4" - 19 ORB | SUM |
| 6. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 8. | KRJ4336 | [2] | HYDRAULIC HOSE,9.50 mm ID x 2200.00 mm | SUM |
| 9. | 168025A1 | [2] | HYDRAULIC HOSE,9.50 mm ID x 1950.00 mm | SUM |
| 10. | 159214A1 | [1] | HYDRAULIC HOSE | SUM1200 mm |
| 11. | 159213A1 | [1] | HYDRAULIC HOSE | SUM1150 mm |
| 22. | KHJ1345 | [2] | HYDRAULIC HOSE,9.52 mm ID x 2150.00 mm | SUM |
| 43. | 152751A1 | [1] | HOSE,95.00 mm ID x 1000.00 mm | SUM |
| 51. | KRJ5903 | [1] | MANIFOLD | SUM |
| 54. | KHJ1397 | [2] | SUPPORT | SUM |
| 58. | KHJ1393 | [2] | CLAMP | SUM |
| 59. | KHJ1396 | [2] | CLAMP | SUM |
| 60. | 627-8012 | [12] | BOLT,Hex, M8 x 1.25 x 12mm, Cl 10.9, Full Thd | SUM Superseded by part number: 43231 |
| 61. | 153081A1 | [12] | WASHER | SUM |
| 62. | 150860A1 | [1] | COLLAR | SUM |
| 63. | 840-168 | [1] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
| 64. | 150071A1 | [1] | MOUNTING CLIP | SUM380 mm |
