神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-021[00]) - TILT CYLINDER ASSEMBLY (PTPA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY01VU0005F1 | [1] | CYLINDER,Double Acting, 50.8mm Rod, 127mm Stroke | KOBAssembly, Tilt, PTPA, Incl 1 - 18 |
| 1. | YY01VU0005S001 | [1] | TUBE | KOB |
| 2. | YY01VU0005S005 | [1] | ROD | KOB |
| 3. | YY01VU0005S010 | [2] | BUSHING | KOB |
| 4. | YY01VU0005S011 | [1] | FITTING | KOBGrease |
| 5. | YY01VU0005S012 | [1] | FITTING | KOBGrease |
| 6. | YY01VU0005S013 | [2] | RING | KOBRetaining |
| 7. | YY01VU0005S014 | [1] | LOCK NUT | KOB |
| 8. | YY01VU0005S015 | [1] | PISTON | KOB |
| 9. | YY01VU0005S002 | [1] | HEAD | KOB |
| 10. | YY01VU0005S016 | [1] | WIPER | SM |
| 11. | YY01VU0005S017 | [1] | O-RING | SM |
| 12. | YY01VU0005S018 | [2] | WEAR RING | SM |
| 13. | YY01VU0005S019 | [2] | WEAR RING | SM |
| 14. | YY01VU0005S020 | [1] | O-RING | SM |
| 15. | YY01VU0005S021 | [1] | BACK-UP RING | SM |
| 16. | YY01VU0005S022 | [1] | O-RING | SM |
| 17. | YY01VU0005S023 | [1] | SEAL | SM |
| 18. | YY01VU0005S024 | [1] | SEAL | SM |
