| 1. | 150919A1 | [2] | ELBOW,90º, 1/2" O-Ring x 1/2" | SUM |
| 2. | 154487A1 | [1] | O-RING | SUM |
| 3. | KHJ10210 | [1] | HYDRAULIC HOSE,12.70 mm ID x 750.00 mm | SUM800 mm |
| 4. | KHJ2562 | [1] | MANIFOLD | SUM |
| 4A. | 153233A1 | [1] | HYDRAULIC OIL FILTER | SUM Superseded by part number: MMJ80010 |
| 5. | 166350A1 | [3] | BOLT | SUMM8 x 20 |
| 6. | KHJ1553 | [1] | ACCUMULATOR | SUM Superseded by part number: KHJ17540 |
| 7. | KRJ5948 | [1] | BRACKET | SUM |
| 8. | 166351A1 | [2] | BOLT,Sems, M10 x 20mm | SUMM10 x 20 |
| 9. | KHJ2304 | [1] | SOLENOID VALVE | SUM Superseded by part number: KHJ15470 |
| 11. | KWJ0067 | [1] | SUPPORT | SUM |
| 12. | 152718A1 | [2] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 13. | 161551A1 | [1] | COVER | SUM |
| 14. | 156559A1 | [2] | BOLT,High Strength, Hex, M6 x 12mm, W/ LW | SUMM6 x 12 |
| 15. | 895-11006 | [2] | WASHER,M6 x 12mm OD x 1.6mm | CAS Superseded by part number: 86588450 |
| 16. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 17. | 154475A1 | [1] | O-RING | SUM |
| 18. | 152127A1 | [6] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 19. | 154467A1 | [6] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 20. | KHJ1442 | [1] | ELBOW | SUM |
| 22. | 159226A1 | [1] | ADAPTER | SUM |
| 24. | 153526A1 | [1] | ELBOW | SUM |
| 25. | 159002A1 | [2] | PLUG | SUMG 1/4 |
| 28. | KRJ4750 | [1] | HOSE,410.00 mm | SUM4100 mm |
| 29. | KBJ2640 | [1] | HOSE | SUM3300 mm |
| 30. | KHJ2344 | [1] | HOSE | SUM2500 mm |
| 31. | KHJ1932 | [1] | HOSE | SUM5400 mm |
| 32. | KHJ12630 | [1] | CHAIN (CE) | SUM5500 mm |
| 34. | 150387A1 | [1] | HOSE | SUM2300 mm |
| 35. | KHJ12640 | [1] | HYDRAULIC HOSE | SUM4500 mm |
| 36. | KHJ1254 | [1] | ELBOW | SUM |
| 37. | KHJ1640 | [1] | HYDRAULIC HOSE | SUM4800 mm |
| 55. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 57. | 167866A1 | [1] | HYDRAULIC HOSE,6.30 mm ID x 700.00 mm | SUM |
| 58. | 159497A1 | [1] | TEE | SUM |
| 60. | 161483A1 | [1] | HOSE ASSY. | SUM |
| 65. | 167666A1 | [1] | FITTING | SUM |
| 67. | 163814A1 | [1] | ELBOW | SUM |
| 68. | 159481A1 | [1] | ADAPTER | SUM |
| 69. | 150933A1 | [1] | ELBOW | SUM |
| 73. | KHJ1799 | [1] | HYDRAULIC HOSE,6.30 mm ID x 2800.00 mm | SUM2800 mm |
| 74. | KHJ2837 | [1] | HYDRAULIC HOSE,6.30 mm ID x 3500.00 mm | SUM |
| 75. | KHJ12650 | [1] | HYDRAULIC HOSE,6.35 mm ID x 4400.00 mm | SUM |
| 76. | 152660A1 | [1] | PLASTIC-RUBBER TUBE | SUM3000 mm Superseded by part number: KHJ19830 |
| 121. | KHR2581 | [3] | CLAMP | SUM380 mm |
| 122. | KHJ1215 | [3] | BOLT,Spcl | SUMM8 x 25 |
| 127. | 150071A1 | [1] | MOUNTING CLIP | SUM380 mm |
| 128. | KHR2584 | [6] | CLAMP | SUM |
| 130. | 150860A1 | [6] | COLLAR | SUM |
| 131. | 840-168 | [1] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
