纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-035-00[01]) - HYDRAULIC CIRCUIT - PILOT - LEAK-OFF RETURN New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
715 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 16. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 17. | 154475A1 | [1] | O-RING | SUM |
| 28. | KRJ4750 | [1] | HOSE,410.00 mm | SUM4100 mm |
| 29. | KBJ2640 | [1] | HOSE | SUM3300 mm |
| 30. | KHJ2344 | [1] | HOSE | SUM2500 mm |
| 31. | KHJ1932 | [1] | HOSE | SUM5400 mm |
| 32. | KHJ12630 | [1] | CHAIN (CE) | SUM5500 mm |
| 34. | 150387A1 | [1] | HOSE | SUM2300 mm |
| 35. | KHJ12640 | [1] | HYDRAULIC HOSE | SUM4500 mm |
| 38. | 152127A1 | [1] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 39. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 40. | 157564A1 | [1] | FLEXIBLE SHEATH | SUM700 mm |
| 41. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 43. | 157854A1 | [1] | HOSE,4mm ID x 750mm L | SUM750 mm |
| 44. | 159497A1 | [1] | TEE | SUM |
| 46. | 163814A1 | [1] | ELBOW | SUM |
| 47. | 162554A1 | [2] | FITTING | SUM |
| 52. | 162826A1 | [1] | ADAPTER | SUM |
| 75. | KHJ12650 | [1] | HYDRAULIC HOSE,6.35 mm ID x 4400.00 mm | SUM |
| 79. | 159002A1 | [1] | PLUG | SUM |
| 81. | KUJ0321 | [1] | MANIFOLD VALVE | SUM |
| 82. | 152718A1 | [2] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 83. | KWV0068 | [1] | HYD. TUBE | SUM |
| 91. | 157584A1 | [1] | ELBOW | SUM |
| 96. | 152264A1 | [1] | HOSE,6.3mm ID x 2200mm L | SUM2200 mm |
| 97. | KAJ3395 | [1] | HYDRAULIC HOSE | SUM800 mm |
| 98. | 159228A1 | [1] | HOSE ASSY. | SUM |
| 99. | KHJ12620 | [1] | HYDRAULIC HOSE | SUM1800 mm |
| 100. | KBJ1447 | [1] | HOSE | SUM1900 mm |
| 101. | 161659A1 | [1] | HYDRAULIC HOSE | SUM700 mm |
| 103. | 152777A1 | [1] | HOSE ASSY. | SUM3200 mm |
| 104. | 157967A1 | [1] | HOSE | SUM2200 mm |
| 106. | 152747A1 | [1] | ADAPTER | SUM |
| 108. | 152128A1 | [3] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 114. | KHJ10220 | [1] | HYDRAULIC HOSE,6.35 mm ID x 250.00 mm | SUM |
| 116. | 155467A1 | [1] | PLUG, DRAIN | SUM |
| 117. | 150919A1 | [1] | ELBOW,90º, 1/2" O-Ring x 1/2" | SUM |
| 118. | 154487A1 | [1] | O-RING | SUM |
| 119. | KRJ5257 | [1] | HYDRAULIC HOSE,12.70 mm ID x 2100.00 mm | SUM |
| 120. | KHJ1529 | [1] | FITTING | SUM |
| 123. | 159025A1 | [1] | CLAMP | SUM |
| 124. | 166350A1 | [2] | BOLT | SUMM8 x 20 |
| 125. | KHR4332 | [1] | GROMMET | SUM315 mm |
| 126. | 159398A1 | [1] | RUBBER BLOCK | SUM |
| 127. | 150071A1 | [1] | MOUNTING CLIP | SUM380 mm |
