神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-002[01]) - FRAME GROUP, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
533 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY52F00376F1 | [1] | Upp. | |
| 1. | YY52F00375F1 | [1] | Upp. | |
| 2. | YY52F01577P1 | [1] | FOAM INSULATION | KOB |
| 3. | YY52F01957P1 | [1] | INSULATION | KOB |
| 4. | ZW13H16000 | [1] | WASHER | KOB |
| 5. | YY52F01571P1 | [1] | GROMMET | KOB |
| 6. | HS53C16085G1 | [1] | SCREW | KOBCap |
| 7. | YY52F01378P1 | [33] | SCREW | KOBCap |
| 8. | YY52F01420P1 | [1] | FOAM INSULATION | KOB |
| 9. | YY52F01421P1 | [1] | FOAM INSULATION | KOB |
| 10. | YY52F01422P1 | [1] | FOAM INSULATION | KOB |
| 11. | YY52F01425P1 | [1] | FOAM INSULATION | KOB |
| 12. | YY52F01426P1 | [1] | FOAM INSULATION | KOB |
| 13. | YY52F01427P1 | [1] | FOAM INSULATION | KOB |
| 14. | YY52F01546P1 | [1] | FOAM INSULATION | KOB |
| 15. | YY52F01547P1 | [1] | RUBBER | KOB |
| 16. | YY52F01548P1 | [1] | FOAM INSULATION | KOB |
| 17. | YY52F01485P1 | [1] | RUBBER | KOB |
| 18. | YY52F01523P1 | [1] | FOAM INSULATION | KOB Superseded by part number: YY52F01702P1 |
| 19. | YY52F01524P1 | [1] | FOAM INSULATION | KOB |
| 20. | YY52F01584P1 | [1] | FOAM INSULATION | KOB |
| 21. | YY52F01567D1 | [1] | FOAM INSULATION | KOB |
| 22. | YY52F01567D8 | [1] | FOAM INSULATION | KOB Superseded by part number: YY52F01567D5 |
| 23. | YY52F01567D7 | [1] | FOAM INSULATION | KOB Superseded by part number: YY52F01567D5 |
| 24. | YY52F01578P1 | [1] | FOAM INSULATION | KOB |
| 25. | YY52F01955P1 | [1] | INSULATION | KOB |
| 26. | YY52F01956P1 | [1] | INSULATION | KOB |
