纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-037-00[01]) - HYDRAULIC CIRCUIT - OPTIONAL - 3-WAY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
293 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 86. | 150933A1 | [1] | ELBOW | SUM |
| 87. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 88. | KHJ0994 | [1] | ADAPTER | SUM |
| 90. | 150913A1 | [2] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 93. | 161483A1 | [1] | HOSE ASSY. | SUM |
| 95. | 164236A1 | [1] | HOSE ASSY. | SUM1000 mm |
| 96. | 159013A1 | [1] | HOSE ASSY. | SUM600 mm |
| 97. | 159235A1 | [1] | HYDRAULIC HOSE | SUM |
| 115. | KHJ10260 | [1] | HYDRAULIC HOSE | SUM4900 mm |
| 116. | MPJ5370 | [1] | HOSE | SUM4700 mm |
| 119. | 156554A1 | [2] | ELBOW | SUM |
| 123. | KHJ1178 | [1] | ELBOW | SUM |
| 124. | 150860A1 | [1] | COLLAR | SUM |
| 125. | 840-168 | [1] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
| 126. | 150496A1 | [1] | MOUNTING CLIP | SUM250 mm |
| 127. | 150071A1 | [1] | MOUNTING CLIP | SUM380 mm |
| 128. | KHJ1951 | [3] | CLAMP | SUM |
| 129. | 627-8012 | [6] | BOLT,Hex, M8 x 1.25 x 12mm, Cl 10.9, Full Thd | SUM Superseded by part number: 43231 |
| 130. | 153081A1 | [6] | WASHER | SUMW M8 |
| 131. | KHR3351 | [1] | HARNESS | SUM |
| 135. | 165405A1 | [2] | CLIP | SUM |
| 136. | 156559A1 | [2] | BOLT,High Strength, Hex, M6 x 12mm, W/ LW | SUMM6 X 12 |
| 137. | KHR2948 | [1] | SWITCH | SUM |
