神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-007[02]) - RADIATOR INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
602 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY05P00031S001 | [1] | RADIATOR | KOBAssy. |
| 2. | YN05P00010S006 | [1] | RADIATOR CAP | KOB Superseded by part number: YN05P00088S032 |
| 3. | 2452U221S18 | [1] | DRAINCOCK/TAP SUPPLY | KOB |
| 4. | 2452U416S6 | [1] | HOSE | KOB |
| 5. | YY05P00031S005 | [1] | FOAM INSULATION | KOB |
| 6. | YB05P00019S006 | [2] | INSULATOR | KOB |
| 7. | YY05P00031S007 | [1] | OIL COOLER | KOB |
| 8. | YN05P00058S031 | [2] | PACKING | KOB |
| 9. | YY05P00031S009 | [1] | FOAM INSULATION | KOB |
| 10. | YY05P00031S010 | [1] | OIL COOLER | KOBAir |
| 11. | YY05P00039S011 | [1] | BRACKET | KOB |
| 12. | YY05P00031S012 | [3] | RUBBER | KOB |
| 13. | YN05P00058S023 | [1] | INSULATOR | SM |
| 14. | YY05P00031S014 | [2] | RUBBER | KOB |
| 15. | YY05P00031S015 | [2] | FOAM INSULATION | KOB |
| 16. | YY05P00047S016 | [1] | SHROUD | KOB |
| 17. | YY05P00031S017 | [1] | PLATE | KOB |
| 18. | YY05P00039S018 | [1] | PLATE | SM |
| 19. | PY05P00002S009 | [14] | BOLT | KOB Superseded by part number: ZM12C08020 |
| 20. | YY05P00031S020 | [2] | RUBBER | KOB |
| 21. | YN05P00068S017 | [1] | RUBBER | KOB |
| 22. | YY05P00031S022 | [1] | RUBBER | KOB |
| 23. | YY05P00031S023 | [1] | RUBBER | KOB |
| 24. | YM05P00019S021 | [4] | COLLAR | SM |
| 25. | YN05P00058S013 | [4] | SEAT CUSHION | SMMount, Rubber |
| 26. | YN05P00058S014 | [4] | SEAT CUSHION | KOBMount, Rubber |
| 27. | ZM22C10030 | [4] | BOLT | KOBSems |
| 28. | YY05P00031S030 | [4] | SCREW | KOBCap |
