纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-081-00[01]) - CIRCUIT, HYDRAULIC-ELECTRICAL - SELF-DETACHING COUNTERWEIGHT SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
875 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 70. | KHJ15330 | [1] | HYDRAULIC HOSE | SUM2000 mm |
| 71. | KHR4065 | [1] | PLASTIC-RUBBER TUBE | SUM350 mm Superseded by part number: KHR21050 |
| 72. | KHJ1076 | [4] | CLAMP | SUM |
| 73. | 159602A1 | [4] | BOLT,Sems, Hex, M6 x 16mm | SUMM6 x 16 |
| 74. | KWJ11060 | [1] | SUPPORT | SUM |
| 75. | 152718A1 | [1] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 76. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 77. | 154475A1 | [1] | O-RING | SUM |
| 78. | KUJ0298 | [1] | MANIFOLD VALVE | SUM |
| 79. | 166052A1 | [4] | BOLT | SUMM10 x 25 Superseded by part number: 11106231 |
| 80. | KUJ0288 | [1] | SOLENOID VALVE | SUM |
| 81. | KTJ2302 | [1] | BRACKET | SUM |
| 82. | 166352A1 | [2] | BOLT | SUMM12 x 30 |
| 83. | 153105A1 | [1] | PLUG | SUM |
| 85. | 157584A1 | [1] | ELBOW | SUM |
| 87. | KTJ2305 | [1] | HYDRAULIC HOSE,9.52 mm ID x 370.00 mm | SUM |
| 97. | 159226A1 | [1] | ADAPTER | SUM |
| 102. | KAJ4281 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1400.00 mm | SUM |
| 103. | KWJ11030 | [1] | HYDRAULIC HOSE,9.52 mm ID x 1150.00 mm | SUM |
| 106. | KHR2581 | [1] | CLAMP | SUM |
| 107. | KHJ1215 | [1] | BOLT,Spcl | SUMM8 x 25 |
| 116. | KHJ2234 | [2] | TEE | SUM |
| 118. | KAJ3534 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1550.00 mm | SUM1350 mm |
| 119. | 167717A1 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1350.00 mm | SUM |
| 120. | 158063A1 | [1] | PLASTIC-RUBBER TUBE | SUM1300 mm Superseded by part number: KHR21050 |
| 121. | 150774A1 | [1] | PLASTIC-RUBBER TUBE | SUM1000 mm Superseded by part number: KHH12760 |
| 126. | KHJ15260 | [2] | HYDRAULIC HOSE | SUM760 mm |
| 127. | 150488A1 | [2] | PLASTIC-RUBBER TUBE | SUM600 mm Superseded by part number: KHR21050 |
| 128. | 162826A1 | [2] | ADAPTER | SUM |
| 129. | KWJ10940 | [1] | SUPPORT | SUM |
| 132. | KHJ15350 | [1] | HYDRAULIC HOSE | SUM1800 mm |
| 133. | KHJ15340 | [1] | HYDRAULIC HOSE | SUM1600 mm |
| 134. | KHR3340 | [1] | PLASTIC-RUBBER TUBE | SUM1700 mm Superseded by part number: KHR21050 |
| 135. | 158064A1 | [1] | PLASTIC-RUBBER TUBE | SUM1500 mm Superseded by part number: KHR21050 |
| 140. | 150071A1 | [1] | MOUNTING CLIP | SUM380 mm |
| 141. | KWJ10960 | [1] | PROTECTION PLATE | SUM |
| 143. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 145. | KRJ4344 | [1] | HYDRAULIC HOSE,9.50 mm ID x 530.00 mm | SUM |
| 146. | 164107A1 | [1] | TEE,3/8" ORB x 3/8" - 19 NPT x 3/8" - 19 NPT | SUM |
| 148. | KHJ1572 | [1] | HYDRAULIC HOSE | SUM2100 mm |
| 174. | KWR10020 | [1] | WIRE HARNESS | SUM |
| 175. | 150636A1 | [1] | BOX | SUM |
| 176. | KUR0055 | [1] | COVER | SUM |
| 178. | KUR0053 | [1] | TOGGLE SWITCH | SUM |
| 179. | KUR0054 | [2] | TOGGLE SWITCH | SUM |
| 180. | KUR0056 | [1] | PANEL | SUM |
| 181. | 150642A1 | [1] | PACKING | SUM |
| 182. | 150875A1 | [6] | SCREW,Phil Truss Hd, M4 x 12mm | SUMM4 x 12 |
| 183. | KUR0091 | [1] | BRACKET | SUM |
| 184. | 166351A1 | [1] | BOLT,Sems, M10 x 20mm | SUMM10 x 20 |
| 185. | KHR2787 | [4] | CLAMP | SUM |
| 186. | 158962A1 | [1] | CLIP | SUM |
| 187. | 167518A1 | [1] | BOLT | SUMM8 x 16 |
| 188. | KHP1718 | [1] | DECAL | SUM |
