神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-014[00]) - HYDRAULIC TANK ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
529 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY33H00049F1 | [1] | Hyd. | |
| 1. | YY33H00026F1 | [1] | Hyd. | |
| 2. | ZS13C16050 | [4] | SCREW | KOBCap |
| 3. | ZW13H16000 | [4] | WASHER | KOB |
| 4. | LE33H01017D1 | [3] | SHIM,1.0mm Thk | KOB1.0 |
| 5. | YY33H01154P1 | [1] | FOAM INSULATION | KOB |
| 6. | YY33H00048F1 | [1] | TANK | KOBAssy., Hyd. |
| 7. | YN50V00025F2 | [1] | STRAINER ASSY. | KOBSuction |
| 8. | YN50V00002S001 | [1] | STRAINER ASSY. | KOB |
| 9. | 2446R110S2 | [1] | HOLDER | KOB |
| 10. | ZN11C10008 | [2] | NUT | KOB Superseded by part number: ZN18C10008 |
| 11. | 2446R110S6 | [1] | SPRING | KOB |
| 12. | YN50V00025S007 | [1] | BOLT | KOB |
| 13. | YN57V00004F1 | [1] | BREATHER | KOBAssy. Superseded by part number: YN57V00010F1 |
| 14. | YN57V00004S002 | [1] | ELEMENT | KOBFilter Superseded by part number: 47640920 |
| 15. | 2446U260S10 | [1] | NUT | KOB |
| 16. | 2446U260S8 | [1] | PACKING | KOB |
| 17. | YN33H01304P1 | [4] | BOLT | KOBBolt |
| 18. | YV52V01003F3 | [1] | Filter | |
| 19. | YN52V01011P2 | [1] | ELEMENT | KOBFilter Superseded by part number: YN52V01021P1 |
| 20. | YN52V01008S002 | [1] | PLATE | KOB |
| 21. | YV21V00001P1 | [1] | CHECK VALVE | KOB |
| 22. | ZD11G09000 | [1] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOB |
| 23. | YN52V01008S005 | [1] | PACKING | KOB |
| 24. | LC33H01009P1 | [1] | SPRING | KOB |
| 25. | YY33H01153P1 | [1] | COVER | KOB |
| 26. | YN33H01259P1 | [1] | COVER | KOB Superseded by part number: YN33H01259P2 |
| 27. | ZM73C10025 | [12] | BOLT,M10x25mm - Course Thread | KOB |
| 28. | YN58S00009F1 | [1] | GAUGE | KOBLevel, Oil |
| 29. | ZE72X08000 | [1] | PLUG | KOB |
| 30. | ZD11G20000 | [1] | O-RING,5.7mm Thk x 199.3mm ID, 70 Duro | KOB |
| 31. | ZD11G19000 | [1] | O-RING,189.30mm ID x 200.70mm OD x 5.70mm | KOB |
| 32. | YY33H00047P1 | [1] | TANK | KOB |
| . . | YV52V01003R300 | [1] | REPAIR KIT | KOBConsists Of Item: 19(1), 22(1), 23(1), 31(1) |
