神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-017[03]) - VALVE INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
382 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 3. | YN30V00001S154 | [2] | PLUG | KOB |
| 4. | YW30V00001S155 | [2] | PLUG | KOB |
| 5. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 6. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 7. | ZD12P01500 | [4] | O-RING | KOB |
| 8. | ZD12P01000 | [7] | O-RING | KOB |
| 9. | YM30V00008S207 | [1] | GUARD | SM |
| 10. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOB |
| 11. | ZD12P03200 | [2] | O-RING | KOB |
| 12. | ZS23C06030 | [5] | SCREW,Hex Socket Head, M6 x 30mm | KOBCap |
| 13. | YM30V00008S517 | [1] | POPPET | SM |
| 14. | YM30V00008S518 | [1] | POPPET | SM |
| 15. | YY30V00058S527 | [1] | SPRING | KOB |
| 16. | YY30V00058S528 | [1] | SPRING | KOB |
| 17. | ZD12P02400 | [2] | O-RING | KOB |
| 18. | ZS23C14130 | [9] | CAPSCREW,Hex Socket Head, M14 x 130mm | KOBSCREW Cap |
