| 1. | YN30V00001S154 | [2] | PLUG | KOB |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONPlug |
| 3. | YW30V00001S157 | [1] | PLUG | KOB |
| 4. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 5. | ZD12G02500 | [6] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOB |
| 6. | ZD12P01500 | [4] | O-RING | KOB |
| 7. | ZD12P01000 | [7] | O-RING | KOB |
| 8. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 9. | YM30V00008S205 | [7] | GUARD | SM |
| 10. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 11. | YM30V00008S305 | [1] | PISTON | SMSpool Superseded by part number: YM30V00008R140 |
| 12. | YM30V00011S306 | [2] | SPOOL | SM |
| 13. | YY30V00058S307 | [1] | SPOOL | SM |
| 14. | YM30V00008S321 | [3] | SPRING | SM |
| 15. | YM30V00008S322 | [3] | SPRING | SM |
| 16. | YM30V00008S325 | [6] | SPRING | SM |
| 17. | YM30V00008S327 | [2] | SPRING | SM |
| 18. | YM30V00008S328 | [3] | SPRING | SM |
| 19. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 20. | 2436U1265S336 | [12] | BOLT | KOB |
| 21. | YM30V00008S336 | [6] | SEAL RETAINER | SMStopper |
| 22. | YM30V00008S339 | [5] | SEAL RETAINER | SMStopper |
| 23. | 2436U1265S511 | [11] | POPPET | KOB |
| 24. | YW30V00001S513 | [2] | POPPET | KOB |
| 25. | 2436U1265S521 | [11] | SPRING | KOB |
| 26. | YN30V00101S522 | [2] | SPRING | SM |
| 27. | YN30V00021S552 | [12] | PLUG | KOB |
| 28. | YW30V00001S556 | [5] | PLUG | KOB |
| 29. | ZD12P02000 | [17] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 30. | ZD12P02400 | [2] | O-RING | KOB |
| 31. | LP22V00001F1 | [1] | VALVE | KOBAssy., Relief |
| 32. | YN22V00002F1 | [5] | VALVE | KOBAssy., Overload |
| 33. | YY30V00058S084 | [6] | COVER ASSY | KOB |
| 34. | YY30V00058S085 | [4] | COVER ASSY | KOB |
| 35. | ZD12G04000 | [12] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 36. | YY30V00058S091 | [1] | | |
| 37. | YY30V000585092 | [1] | | |
| . . | YY30V00058R100 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 14(1), 15(1) |
| . . | YY30V00058R120 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 11(1), 16(1), 22(1) |
| . . | YY30V00058R110 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 16(1), 22(1) |
| . . | YY30V00063R130 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 12(1), 14(1), 15(1), 24(1) |
| . . | YM30V00008R140 | [1] | KIT | SMRepair, Consists Of Item: 13(1), 16(1), 22(1) |
| . . | YY30V00058R160 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 17(1), 22(1) |
| . . | YM30V00011R150 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 17(1), 24(1) |
| . . | YY30V00058R170 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 17(1), 18(1), 24(1) |
| . . | YM30V00008R200 | [1] | KIT | SMRepair, Consists Of Item: 19(1), 20(1), 23(1) |
| . . | YY30V00058R210 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 17(1), 22(1) |
| . . | YY30V00058R220 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 17(1), 22(1) |
