纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-101-00[01]) - HIGH PRESSURE PUMP - REGULATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
701 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 88. | LJ01299 | [1] | REGULATOR | SUM |
| 89. | 108R006Z060R | [4] | SCREW | SUMM6 x 60 Superseded by part number: 861-6060 |
| 90. | 108R008Z050N | [2] | BOLT | SUM |
| 91. | 861-8070 | [2] | HEX SOC SCREW,M8 x 70mm, Cl 12.9 | CASM8 x 70 |
| 92. | 861-6030 | [2] | HEX SOC SCREW,M6 x 30mm, Cl 12.9 | SUMM6 x 30 Superseded by part number: 108R006Z030N |
| 93. | 862-6020 | [6] | HEX SOC SCREW,M6 x 20mm, Cl 12.9 | CASM6 x 20 |
| 94. | 155496A1 | [1] | PLUG | SUM |
| 95. | LK00003 | [6] | PLUG | SUM |
| 96. | NSS | [2] | NOT SERVICED SEPARATELY | CON |
| 128. | 154685A1 | [1] | O-RING | SUM |
| 129. | 154449A1 | [3] | O-RING | SUM |
| 130. | 154457A1 | [8] | O-RING | SUM |
| 131. | 154465A1 | [1] | O-RING | SUM |
| 132. | 154489A1 | [1] | O-RING | SUM |
| 133. | 154501A1 | [1] | O-RING | SUM |
| 134. | 154485A1 | [2] | O-RING | SUM |
| 135. | 154493A1 | [1] | O-RING | SUM |
| 136. | 154513A1 | [1] | O-RING | SUM |
| 137. | 154473A1 | [1] | O-RING | SUM |
| 138. | 154469A1 | [11] | O-RING | SUM |
| 139. | 154517A1 | [1] | O-RING | SUM |
| 140. | 154553A1 | [1] | O-RING | SUM |
| 141. | LA00065 | [2] | JAM NUT | SUMM8 x 1 |
| 142. | 800-1110 | [1] | SNAP RING,M10, Ext | CAS Superseded by part number: 3991509 |
| 144. | 800-2115 | [2] | SNAP RING,M15, Int | CAS Superseded by part number: 11057376 |
| 150. | LA00759 | [1] | BOLT,Hex Skt Hd | SUM |
