| 1. | YT30V00009S153 | [1] | PLUG | SM |
| 2. | ZD12G03000 | [13] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 3. | ZD12G02500 | [6] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOB |
| 4. | ZD12P01000 | [7] | O-RING | KOB |
| 5. | YM30V00008S205 | [7] | GUARD | SM |
| 6. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 7. | ZS23C08025 | [40] | SCREW,Hex Socket Head, M8 x 25mm | KOBCap |
| 8. | ZS23C12025 | [4] | CAPSCREW,Hex Socket Head, M12 x 52mm | KOBSCREW Cap |
| 9. | ZS23C12035 | [4] | SCREW,Hex Socket Head, M12 x 35mm | KOBCap |
| 10. | YY30V00058S308 | [1] | SPOOL | SM |
| 11. | YM30V00008S311 | [1] | PISTON | SMSpool Superseded by part number: YM30V00008R200 |
| 12. | YM30V00008S325 | [6] | SPRING | SM |
| 13. | YM30V00008S326 | [1] | SPRING | SM |
| 14. | YM30V00008S329 | [1] | SPRING | SM |
| 15. | YM30V00008S330 | [1] | SPRING | SM |
| 16. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 17. | 2436U1265S336 | [12] | BOLT | KOB |
| 18. | YM30V00008S337 | [1] | SEAL RETAINER | SMStopper |
| 19. | YM30V00008S339 | [5] | SEAL RETAINER | SMStopper |
| 20. | 2436U1265S511 | [11] | POPPET | KOB |
| 21. | YM30V00008S515 | [1] | POPPET | SM |
| 22. | 2436U1265S521 | [11] | SPRING | KOB |
| 23. | YN30V00021S552 | [12] | PLUG | KOB |
| 24. | ZD12P02000 | [17] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 25. | YN30V01062P1 | [2] | PLUG | SMAssy. |
| 26. | YN30V00120F2 | [2] | VALVE | KOBControl |
| 27. | YN22V00029F1 | [1] | VALVE | KOBAssy., Overload |
| 28. | YY30V00058S084 | [6] | COVER ASSY | KOB |
| 29. | YY30V00058S088 | [1] | PLATE | KOB Superseded by part number: YF30V00011S212 |
| 30. | YY30V00058S089 | [1] | PLATE | KOB Superseded by part number: YM30V00008S213 |
| 31. | ZD12G04000 | [12] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| . . | YY30V00058R100 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 18(1) |
| . . | YY30V00058R110 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 12(1), 13(1), 18(1), 19(1) |
| . . | YY30V00058R120 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 12(1), 13(1), 18(1), 19(1) |
| . . | YY30V00063R130 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 18(1) |
| . . | YM30V00008R140 | [1] | KIT | SMRepair, Consists Of Item: 12(1), 13(1), 18(1), 19(1) |
| . . | YM30V00011R150 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 10(1), 14(1), 18(1) |
| . . | YY30V00058R160 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 15(1), 18(1), 19(1) |
| . . | YY30V00058R170 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 18(1) |
| . . | YM30V00008R200 | [1] | KIT | SMRepair, Consists Of Item: 16(1), 17(1), 18(1), 20(1) |
| . . | YY30V00058R210 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 15(1), 18(1), 19(1) |
| . . | YY30V00058R220 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 15(1), 18(1), 19(1) |
