神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-019[01]) - VALVE INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
119 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY64H00216F1 | [1] | | |
| 1. | YY30V00048F1 | [1] | CONTROL VALVE | KOBAssy. |
| 2. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 3. | 2436U2796S2 | [2] | TIE-ROD | KOB |
| 4. | 2436U424S9 | [2] | NUT | KOB |
| 5. | 2436U2796S4 | [1] | TIE-ROD | KOB |
| 6. | YR20V00001F1 | [1] | VALVE | KOBHyd. |
| 7. | 2436R329F1 | [1] | OUTLET | KOBSection Assy. |
| 8. | YY30V00051F1 | [2] | MANIFOLD | KOBValve Assy., Control |
| 9. | YY30V00052F1 | [1] | MANIFOLD | KOBValve Assy., Control |
| 10. | 2436R1119F7 | [1] | HYDRAULIC VALVE | KOBAssy., Relief |
| 11. | YT22V00006F4 | [6] | VALVE | KOBAssy., Relief |
| 12. | YR30V00014S010 | [8] | PLUG | KOB |
| 13. | 2436U2937S18 | [6] | PLUG | KOB |
| 14. | YY64H01152P1 | [1] | BRACKET | KOB |
| 15. | YY64H01169P1 | [1] | BRACKET | KOB |
| 16. | ZM73C08035 | [3] | BOLT,M8x35mm - Course Thread | KOBSems |
| 17. | ZM73C12030 | [4] | BOLT,M12x30mm - Course Thread | KOBSems |
| 18. | ZS18C12035 | [1] | SCREW,Hex, M12 x 35mm | KOBCap |
| 19. | ZW16H12000 | [1] | WASHER | KOB |
