神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-019[02]) - VALVE INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
497 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YR20V00001S001 | [1] | BODY | KOB |
| 2. | 2436R328S2 | [1] | O-RING | KOB Superseded by part number: 45Z91D84 |
| 3. | 2436R1163S3 | [1] | PLATE | KOBName |
| 4. | 2436R680S14 | [4] | RIVET | KOB |
| 5. | 2436R919S12 | [1] | CAP | KOB |
| 6. | 2436R919S9 | [1] | END | KOBSpool |
| 7. | 2436R919S10 | [1] | SEAT | KOBSpring |
| 8. | YY30V00051S006 | [1] | SPRING | KOB |
| 9. | 2436R919S8 | [1] | SEAT | KOBSpring |
| 10. | 2436R668S3 | [2] | O-RING | KOB |
| 11. | 2436R919S7 | [1] | CAP | KOB |
| 12. | ZS23C06018 | [1] | SCREW,Hex Socket Head, M6 x 18mm | KOBCap |
| 13. | 2436R331S10 | [1] | POPPET | KOB |
| 14. | 2436U389S12 | [1] | SPRING | KOB |
| 15. | 45Z91D84 | [1] | O-RING | KOB |
