神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-020[04]) - HYDRAULIC LINES, PUMP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
911 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY30H00029F1 | [1] | Pump | |
| 2. | YF10V00009F1 | [1] | PUMP | KOBPump |
| 3. | YY30H01035D1 | [1] | HOSE | KOB |
| 4. | YR03H01066P2 | [1] | ELBOW | KOB |
| 5. | HH25S16016G1 | [1] | HYD CONNECTOR | KOB |
| 6. | YY30H01056P1 | [1] | ELBOW | KOB |
| 7. | HH45S16016G1 | [1] | ELBOW | KOB |
| 8. | ZE72X04000 | [1] | PLUG | KOB |
| 9. | 45Z91D104 | [1] | O-RING,3.53mm Thk x 69.44mm ID, 80 Duro | KOB Superseded by part number: 923582 |
| 10. | ZS28C10030 | [2] | SCREW,Hex Socket Head, M10 x 30mm | KOBCap |
| 11. | ZS28C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBScrew |
| 12. | ZW16P10000 | [2] | WASHER | KOB |
| 13. | ZW26K12000 | [4] | LOCK WASHER | KOB |
| 14. | YY30H01051P1 | [1] | BLOCK | KOB |
| 15. | YM30H01008P1 | [1] | FLANGE | KOB |
| 16. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| 17. | ZD12P03800 | [1] | O-RING | KOB |
| 18. | ZS28C10045 | [4] | SCREW,Hex Socket Head, M10 x 45mm | KOBCap |
| 19. | ZS28C10090 | [4] | SCREW,Hex Socket Head, M10 x 90mm | KOBCap |
| 20. | ZW26K10000 | [8] | LOCK WASHER | KOBLock Superseded by part number: 12581679 |
