纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-252-00[01]) - VALVE SOLENOIDE - OPTIONAL - 3-WAY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
263 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | 162538A1 | [1] | VALVE | SUM |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | 155456A1 | [1] | PLUG | SUM |
| 4. | 156048A1 | [1] | SPRING | SUM |
| 4A. | LSC0278 | [1] | COMPRESSION SPRING | SUM |
| 5. | 162724A1 | [1] | SOLENOID | SUM |
| 5A. | CDP0873 | [1] | SOLENOID VALVE | SUM |
| 6. | 862-4010 | [4] | HEX SOC SCREW,M4 x 10mm, Cl 12.9 | SUM Superseded by part number: 14302971 |
| 6A. | 160298A1 | [4] | BOLT,Hex Skt | SUM |
| 7. | 154463A1 | [1] | O-RING | SUM |
| 7A. | 154462A1 | [1] | O-RING | SUM |
| 8. | 154475A1 | [1] | O-RING | SUM |
| 8A. | 154482A1 | [1] | O-RING | SUM |
