神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-021[01]) - HYDRAULIC LINES, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
359 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY03H00236F1 | [1] | Upp. | |
| 1. | YY03H00226F1 | [1] | Upp. | |
| 2. | ZG33F10008 | [1] | 90 ELBOW,1"-14 UNS x PF 1/2" | KOB |
| 3. | HG34F10008G1 | [1] | 90 ELBOW,1"-14 UNS x PF 1/2", O-Ring | KOB |
| 4. | ZS18C10055 | [2] | SCREW,Hex, M10 x 55mm | KOBCap |
| 5. | YY03H01205P1 | [1] | SUPPORT | KOB |
| 6. | ZM73C12040 | [2] | BOLT,M12x40mm - Course Thread | KOBSems |
| 7. | YY03H01201P1 | [1] | TUBE | KOB |
| 8. | YY03H01202P1 | [1] | TUBE | KOB |
| 9. | ZX20H10145 | [1] | HYD CONNECTOR | KOB |
| 10. | ZX30H10130 | [1] | HOSE ASSY. | KOB |
| 11. | ZX20H10110 | [1] | HOSE ASSY. | KOB |
| 12. | ZX20H10096 | [1] | HOSE ASSY. | KOB |
| 13. | ZX20H10120 | [1] | HOSE | KOB |
| 14. | ZX30H10092 | [1] | HOSE ASSY. | KOB |
| 15. | ZX20H10072 | [1] | HOSE | KOB |
| 16. | ZX30H10115 | [1] | HOSE ASSY. | KOB |
| 17. | ZD12A01600 | [19] | O-RING | KOB |
| 18. | ZW16H10000 | [2] | WASHER | KOB |
| 19. | ZC36M22011 | [2] | CLAMP | KOB |
| 20. | PV02B01073D3 | [2] | CAP | KOB Superseded by part number: YN64H01391D1 |
| 21. | YY03H00100F1 | [1] | Upp. | |
| 22. | YY03H01343D1 | [1] | HOSE ASSY. | KOB |
| 23. | YY03H01343D2 | [1] | HOSE ASSY. | KOB |
| 24. | YY03H01344D1 | [1] | HOSE ASSY. | KOB |
| 25. | YY03H01343D3 | [1] | HOSE ASSY. | KOB |
