神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-021[02]) - HYDRAULIC LINES, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
944 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ZG33F10012 | [8] | 90 ELBOW,1"-14 UNS x PF 3/4" | KOB |
| 2. | ZG33F12012 | [1] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB |
| 3. | YY03H01246P1 | [1] | CLAMP | KOB |
| 4. | YY03H01247P1 | [1] | CLAMP | KOB |
| 5. | ZG23F10012 | [3] | HYD CONNECTOR | KOB |
| 6. | ZM73C12030 | [4] | BOLT,M12x30mm - Course Thread | KOBSems |
| 7. | HS18C12160G1 | [2] | SCREW,M12 x 160mm, Cl 10.9 | KOBCap |
| 8. | YY03H01263P1 | [1] | BRACKET | KOB |
| 9. | ZW16H12000 | [2] | WASHER | KOB |
| 10. | YY03H01250P1 | [1] | PLATE | KOB |
| 11. | ZS18C08080 | [2] | SCREW,Hex, M8 x 80mm | KOBCap |
| 12. | ZW16H08000 | [2] | WASHER | KOB |
| 13. | ZX20H10145 | [1] | HYD CONNECTOR | KOB |
| 14. | ZX30H10130 | [1] | HOSE ASSY. | KOB |
| 15. | ZX20H10110 | [1] | HOSE ASSY. | KOB |
| 16. | ZX20H10096 | [1] | HOSE ASSY. | KOB |
| 17. | ZX20H10120 | [1] | HOSE | KOB |
| 18. | ZX30H10092 | [1] | HOSE ASSY. | KOB |
| 19. | ZX20H10072 | [1] | HOSE | KOB |
| 20. | ZX30H10115 | [1] | HOSE ASSY. | KOB |
| 21. | ZD12A01600 | [19] | O-RING | KOB |
| 22. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| 23. | YY03H01343D1 | [1] | HOSE ASSY. | KOB |
| 24. | YY03H01343D2 | [1] | HOSE ASSY. | KOB |
| 25. | YY03H01344D1 | [1] | HOSE ASSY. | KOB |
| 26. | YY03H01343D3 | [1] | HOSE ASSY. | KOB |
| 27. | YT32H01030P1 | [1] | BUSHING | KOB |
| 28. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB |
| 29. | YY03H00104F1 | [1] | Upp. | |
| 30. | YY03H01294P1 | [2] | BUSHING | KOB |
| 31. | YY03H01224P1 | [2] | BUSHING | KOB |
| 32. | YY03H01225P1 | [1] | BUSHING | KOB |
