纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-257-00[01]) - CUSHION VALVE - PILOT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
429 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | KUJ10020 | [1] | VALVE SECTION | SUM Superseded by part number: KWJ11220 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 7. | LK00445 | [4] | ADAPTER | SUM |
| 8. | LH00383 | [4] | RETAINER | SUM |
| 9. | 153106A1 | [2] | COLLAR | SUM |
| 10. | 153117A1 | [4] | COLLAR | SUM |
| 11. | 153109A1 | [4] | SPRING | SUM |
| 12. | 153114A1 | [4] | SPRING | SUM |
| 13. | 153107A1 | [4] | SPRING | SUM |
| 14. | 154486A1 | [4] | O-RING | SUM |
| 15. | 154474A1 | [4] | O-RING | SUM |
| 16. | 154454A1 | [2] | O-RING | SUM |
| 17. | 161004A1 | [17] | PLUG | SUM |
