神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-022[01]) - GRIP ASSEMBLY PN YM03MU1012P1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
906 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM03MU1012P1 | [1] | GRIP | KOB(Includes Harness) Page 1 of 2 |
| 1. | YM03MU1012P1001 | [1] | HANDLE | KOBHandle |
| 2. | YM03MU1012P1002 | [1] | Cover | |
| 3. | YM03MU1012P1003 | [1] | ADAPTER | KOBM14x2.0x38mm Long |
| 4. | 2479U2167 | [1] | SWITCH | KOBRocker |
| 5. | 2479U2168 | [1] | SWITCH | KOBPush Button |
| 6. | 2420Z2332 | [2] | SCREW | KOB4/40, 1/4 in Long Roundhead, Hex Socket |
| 7. | 2420Z2333 | [2] | Screw, 8/32, 1in Long Flathead, Hex Socket | |
| 8. | 2420Z2334 | [1] | NUT | KOBM14 |
| 9. | 2479U2175 | [1] | Connector - Alternate, Serial Range: Part-24100J18668S101 | |
| 9. | 24100J18668S101 | [1] | HOUSING | KOBConnector - Alternate, Serial Range: Part-2479U2175 |
| 10. | 2479U2176 | [4] | Terminal, Wire - Alternate, Serial Range: Part-24100J18668S103 | |
| 10. | 24100J18668S103 | [4] | HOUSING | KOBTerminal, Wire - Alternate, Serial Range: Part-2479U2176 |
