神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-021[04]) - HYDRAULIC LINES, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
146 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY03H00157F1 | [1] | Upp. | |
| 2. | YY03H01303D1 | [1] | HOSE ASSY. | KOB |
| 3. | YY03H01304D1 | [1] | HOSE ASSY. | KOB |
| 4. | YY03H01305D1 | [1] | HOSE ASSY. | KOB |
| 5. | YY03H01306D1 | [1] | HOSE ASSY. | KOB |
| 6. | YY03H01306D2 | [1] | HOSE ASSY. | KOB |
| 7. | YY03H01306D3 | [1] | HOSE ASSY. | KOB |
| 8. | 2444Z3715 | [1] | 90 ELBOW | KOB |
| 9. | YR03H01066P2 | [1] | ELBOW | KOB |
| 10. | ZH32X06008 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB |
| 11. | ZH32X08000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOB |
| 12. | ZH42X08000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOB45 |
| 13. | YR03H01125P1 | [3] | HYD CONNECTOR | KOB |
| 14. | YT32H01021P1 | [2] | GROMMET | KOB |
| 15. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB |
